1238

Overview

Basic Info.

Model NO.	1238-5621
Surface Treatment	Polishing
Customized	Customized
Standard	Standard
PWM Operating Frequency	15 kHz
Package Environmental Rating	IP65
Used in	Liftstar & Mima Electric Forklifts
Brand	Curtis
Maximum Encoder Frequency	15 kHz
Color	Black
Net Weight	3.9kg
Application	Electric Vehicle
Product Name	AC Motor Controller
Transport Package	Standard Exporting Packaging
Specification	229*178*81 mm
Trademark	ECAS
Origin	China
HS Code	8537109090
Production Capacity	3000 Pieces/Month

Packaging & Delivery

Package Size 18.00cm * 10.00cm * 9.00cm Package Gross Weight 2.000kg

Product Description

A range of controllers (inverters) for the speed and torque control of 3-phase AC motors. Intended for use as electric traction or hydraulic pump motor controllers for mobile, on-vehicle applications that use a 24-96 VDC nominal battery supply.FEATURES Increased Performance, Improved Functionality Higher peak current rating allows use of a physically smaller controller for a given load, for easier installation in any vehicle. CE marked as a programmable safety device under EN ISO 13849-1. Models available for 250A-1000A output at 24-96V system voltages. These are true 2 minute RMS ratings, not short duration 'boost' ratings. Enhanced 64 MHz micro and additional FLASH memory doubles the available VCL code space and provides more than twice the VCL execution speed. VCL-configurable CAN 'mailboxes' provide highly flexible CAN capabilities. Advanced Pulse Width Modulation techniques produce low motor harmonics, low-torque ripple and minimized heating losses, resulting in high efficiency.Unmatched Flexibility Programmable for either traction or pump applications. Field upgradeable software. Integrated Battery state-of-charge algorithm and hour meters. Fully-featured generic software and VCL for typical Warehouse Truck applications is included. Comprehensive programming options and VCL allow other applications to be easily supported. Curtis hand-held or PC Windows programming tools provide easy programming and powerful system diagnostic tools. Integrated status LED provides instant diagnostic indication.

Product Description

sProgrammable Controller 600A MultiMode SepEx 1244-5651 DC Motor Speed Controller 36V

Product nume	AC Motor Controller	Car Fitment	Electric Sightseeing Bus lifted Golf Cart forlift etc.MIMA, HELI, HANGCHA, NOBLELIFT, EP, TCM, LIFTSTAR, XILIN, HYSTER, etc.
Voltage Options	36-48V	Current	650A
Model	1238-5621	Temperature	-40°C to 50°C
Color	Black	Type	AC Motor
Size	L229*178*81mm	Warranty	1 year
MOQ	20 PCS	Port	Ningbo/Shanghai

The 'E' Advantage A significant enhancement to the Curtis AC family, The 'E' models utilize a powerful dual-microprocessor logic architecture to provide improved performance and surpass the requirements of the latest international functional safety standards. Only AC can offer: VCL™-Vehicle Control Language is an easy to use programming language that allows vehicle developers to write powerful logic functions and create a 'virtual system controller'. Curtis offers customers VCL development tools and training. Curtis also provides a VCL service where Curtis engineers will work with the OEM to create anycustom VCL code required. Indirect Field Orientation (IFO) Vector Control algorithm generates the maximum possible torque and efficiency across the entire speed range. Advanced Curtis IFO vector control provides superb drive 'feel', improved speed regulation and increased gradeability. Auto-Tune function enables quick and easy characterization of the AC motor without having to remove it from the vehicle. Curtis AC controllers are fully compatible with any brand of AC motorDual-Drive Functionality is standard, allowing correct control of applications featuring twin traction motors. This function ensures smooth and safe operation, minimal tire wear and correct load sharing between the traction motors at all times. Configurable CANbus connection allows communication with other CANbus enabled devices. Models 1236E and 1238E are CANopen compatible and provide 20 VCLconfigurable CAN 'mailboxes', 6 more than earlier Curtis AC controllers. Integrated System Controller-More than just a motor controller, they are also powerful system controllers. They feature a comprehensive allocation of multifunction I/O pins for use as analog inputs, digital inputs, contactor coil drivers and proportional valve drivers. In addition to this local I/O, these controllers can use VCL to map and configure the remote I/O available on other CANbus devices, send messages to CAN displays and thus control and monitor the entire system..FEATURES Increased Performance, Improved functionality Higher performance form, fit and functional replacements for earlier Model 1236 and 1238 AC controllers. CE marked as a programmable safety device under EN ISO 13849-1. Models available for 350-800A output at 24-96V system voltages. These are true 2 minute RMS ratings, not short duration 'boost' ratings. Enhanced 64MHz micro and additional FLASH memory doubles the available VCL code space and provides more than twice the VCL execution speed. Six additional VCL-configurable CAN 'mailboxes' significantly increases CAN master capabilities. Advanced Pulse Width Modulation techniques produce low motor harmonics, low torque ripple and minimized heating losses, resulting in high efficiency
1

Application

Our Advantages

Related Hot sale Products

Hot sale orchard lifting and picking equipment,If you are interested, you can click the link to view.

Package and Delivery

We have a 24 hours *7 days friendly and professional customer service team, providing a strongly 1-year warranty and free lifelong technical support. All Products will be tested for capacity and checked for external damage before packaging. And we provide English guideline and user manual to help you operate Products easily and quickly.

Company Profile

Anhui Ekofil Autoparts Company

Our company is located in HEFEI City, ANHUI Province China, is the large-scale professional agriculture Machinery,Forklift Parts manufacturer with integration of manufacturing, export and after-sale service. Establish in 2017, by now Forklift electrical accessories basically cover the vehicles of major domestic brands( Such as Zhongli,Nuoli,Afterburner,Heli,Baoli,TCM TEU)The company′s main products cover Electric Vehicles,Electric Forklifts,Motor Controller ,Lithium battery and sell parts and accessories for electric Vehicles ,including motors Electric Controls ,meters,accelerators,control handles ,DC converters,power connectors ,wiring harness,Various electrical switches and so on.We have professional quality inspection department, every machine will be tested 3 times before delivery in order to make sure the machinery in future. With high quality product, competitive price, and best after-sale service, we have gained good reputation from all over the world, such as Europe, South Korea North, America, Central and South America, Africa, Australia, New Zealand and so on.Base on it ,we welcome buyers from all over the world.
